AIMA

AIMA Liberty

Embrace Liberty


Basic info


Dimensions (L x W x H)1780x700x1100
Weight100KG (containing batteries)
Seat Height720mm
Seat Length600mm
Pedal Length390mm
Wheel Base1270mm
Ground Clearance130mm
Weight Supported150KG

Motor


Motor TypeHub Motor
Rated Power1200W
Peak Power2066W
Max. Torque102N.m
Climbing Angle14°
Max. Speed53km/h

Battery


Battery TypeGRAPHENE BATTERY
Battery Voltage72V
Battery Capacity26AH
Max. Range65(WMTC)
Battery Weight43.2±0.5KG
Charger Output Current5A
Charging Time6-7h

TIRES & BRAKES


Tire SizeTUBELESS 3.0-10
Shock AbsorberF&R: Hydraulic
Brake (Front/Rear)F: Disc/R: Disc

Lighting System


HeadlightLED
Tail LightLED
Braking LightLED

Others


SpeedometerLED
Frame MaterialQ195
Storage Space18L
